MITSUBISHI Q20UDHCPU Product information and technical parameters：
Brand: MITSUBISHI
Name: General purpose CPU
Model: Q20UDHCPU
Specification model: Q20UDHCPU.
Input / output points: 4096 points.
Number of input and output elements: 8192.
Program capacity: 200 K step.
Processing speed: 0.0095 s.
Program memory capacity: 800 KB.
Support USB and RS232.
Support installed memory card.
Providing high speed communication between multiple CPU.
High speed and high precision data processing.
The processing speed of the real number (floating point) arithmetic has been greatly improved,
Addition instruction reached 0.014 mu s,
Therefore, it can support the request of high-speed, high-precision processing data processing.
In addition, the new addition of double precision floating point arithmetic instructions,
Simplify the programming, reduces the computational error when executing complex formula.
Shorten the fixed scan interrupt time, high precision device.
The minimum interval of the fixed period interrupt program is reduced to 100 s.
The high speed signal can be accurately obtained, which makes the contribution to the higher precision of the device.
