MR-J4W2-44B | MITSUBISHI Multi axis servo drive MR-J4W2-44B
MITSUBISHI MR-J4W2-44B Manual And Instructions
MR-J4W2-44B datasheetPDF datasheet
MITSUBISHI MR-J4W2-44B Product information and technical parameters：
Brand: MITSUBISHI
Name: Multi axis servo drive
Model: MR-J4W2-44B
Multi axis integrated servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Axis number: 2 axis.
Rated output A axis (Note 1): 0.4kw.
Rated output B axis (Note 1): 0.4kw.
Interface: SSCNET III /H.
Note the 1:A axis, B axis, C axis indicates the name of a type of multi axis servo amplifier axis. The C axis represents the 3 axis one type servo amplifier.
Support SSCNET III /H. 1 unit can drive 2 servo motor two axis servo amplifier.
More energy saving, space saving, less wiring, low cost.
Inherited the high performance and high reliability.
Will, as always, adhere to and uphold the excellent quality of MELSERVO.
MR-J4 has inherited the excellent design of existing products.
Its essence to its dregs, create advantage and cost effective utilization rate,
Make full use of renewable resources, to create a new product.
