MR-J4-11KA4 | MITSUBISHI Servo driver MR-J4-11KA4
MITSUBISHI MR-J4-11KA4 Manual And Instructions
MR-J4-11KA4 datasheetPDF datasheet
MITSUBISHI MR-J4-11KA4 Product information and technical parameters：
Brand: MITSUBISHI
Name: Servo driver
Model: MR-J4-11KA4
1 axis servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Rated output: 11.0kw.
Interface: General purpose.
Power supply: three phase AC400V.
0.6kW and 1kW above the servo amplifier.
Servo amplifier supporting universal interface.
Servo amplifier for universal interface.
Speed / torque control of position control and analog voltage command can be carried out by using pulse train command.
Support Max instruction pulse frequency 4 Mpulses/s.
Improve mechanical properties by high performance motor.
By improving the resolution and processing speed of the encoder,
The rotating servo motor has higher precision and better performance of rotation.
Only open a key type of adjustment function, can be carried out including mechanical resonance filter, high end seismic control II, low pass filter servo gain adjustment.
Easily start advanced seismic function, it can maximize the mechanical properties.
It can automatically adjust the required response settings automatically.
