Multi axis integrated servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Axis number: 2 axis.
Rated output A axis (Note 1): 0.75kw.
Rated output B axis (Note 1): 0.75kw.
Interface: SSCNET III /H.
Note the 1:A axis, B axis, C axis indicates the name of a type of multi axis servo amplifier axis MITSUBISHI MR-J3ENCBL2M-A1-L. The C axis represents the 3 axis one type servo amplifier MR-J3ENCBL2M-A1-L
Support SSCNET III /H. 1 unit can drive 2 servo motor two axis servo amplifier.
More energy saving, space saving, less wiring, low cost.
Inherited the high performance and high reliability.
Will, as always, adhere to and uphold the excellent quality of MELSERVO.
MR-J4 has inherited the excellent design of existing products MITSUBISHI MR-J3ENCBL2M-A1-L.
Its essence to its dregs, create advantage and cost effective utilization rate,
Make full use of renewable resources, to create a new product. Motor series: ultra low inertia, small capacity.
Using a serial absolute / incremental encoder.
Rated output power: 0.75kw.
Rated speed: 3000rpm.
With the brake with brake.
Without GB.
Shaft end: straight shaft.
The rotor of the servo motor is a permanent magnet, and the control of the servo amplifier is controlled by the U/V/W three-phase electric electromagnetic field,
The rotor rotates under the action of the magnetic field, and the encoder feedback signal of the motor is given to the driver,
According to the feedback value and the target value, the driver is compared,
Adjust the rotor rotation angle MITSUBISHI MR-J3ENCBL2M-A1-L.
The accuracy of the servo motor is determined by the resolution of the encoder. Servo motor series: medium inertia, medium power.
Rated output: 3.5kw.
Rated speed: 2000r/min.
Electromagnetic brake: No.
Shaft end specification: Standard (straight axis).
Characteristics: medium inertia has two types of low speed and high speed, suitable for different applications.
IP level: IP67.
Application example:
1, material handling system.
2, industrial robots.
3, X-Y working table.
The protection level of the HF-SP/HF-JP series servo motor is IP67 (except the shaft part).
Motor capacity selection soft (MRZJW3-MOTSZ111E)
Friendly interface design, only in the mechanical description window input constant and operation mode can choose the best servo amplifier,
The servo motor and the regenerative braking options, but also in the selection window in the selection of linear servo mootor and direct drive motor MR-J3ENCBL2M-A1-L.
Characteristic
(1) 10 typical mechanical transmission structure can be used to choose
(2) user defined operating modes (location and speed control)
(3) in the selection process, the feed speed and torquue can be displayed in a graphical format MR-J3ENCBL2M-A1-L.
(4) the calculation process can be displayed
Can easily calculate the power of the servo motor free software!
