HG-JR11K1MB | MITSUBISHI High capacity servo motor in low inertia HG-JR11K1MB
MITSUBISHI HG-JR11K1MB Manual And Instructions
HG-JR11K1MB datasheetPDF datasheet
MITSUBISHI HG-JR11K1MB Product information and technical parameters：
Brand: MITSUBISHI
Name: High capacity servo motor in low inertia
Model: HG-JR11K1MB
Servo motor series: low inertia, medium and large capacity.
Rated output: 11.0kw.
Rated speed; 1500r/min.
Electromagnetic brake: incidental.
Power supply: 200V.
Most suitable for medium and large capacity, low inertia type products in high frequency operation or acceleration and deceleration operation.
Improve the environmental performance of HG-SR, HG-JR series of products using IP67.
High speed & high torque. Shorten the positioning time, achieve high-speed equipment.
100 scene, there are 100 different drive control.
In order to meet the needs of the diverse and detailed field,
MR-J4 product line configuration, providing a wealth of servo amplifier and servo motor products.
Can meet the different needs of different customers.
