HA-LF22K1M | MITSUBISHI Low inertia medium capacity motor HA-LF22K1M
MITSUBISHI HA-LF22K1M Manual And Instructions
HA-LF22K1M datasheetPDF datasheet
MITSUBISHI HA-LF22K1M Product information and technical parameters：
Brand: MITSUBISHI
Name: Low inertia medium capacity motor
Model: HA-LF22K1M
Motor series: low inertia, medium capacity.
Rated output power: 22.0kw.
Rated speed: 1500rpm.
With the brake: without.
Shaft end: straight shaft.
The rotor of the servo motor is a permanent magnet, which is controlled by the U/V/W,
The rotor rotates under the action of the magnetic field, and the encoder feedback signal of the motor is given to the driver,
According to the feedback value and the target value, the driver adjusts the rotation angle of the rotor.
Accuracy of the servo motor depends on the accuracy of the encoder (number of lines).
