Express PCI bus.
Support japanese.
Ethernet cable.
Linear / star (linear and star can be mixed use)
Field network (control station / common station).
MELSECNET/H network module capable of composing large scale flexible network system.
The MELSECNET/H network system includes the PLC network of the control station and the communication between the stations and the remote I/O network in the remote station remote I/O station MITSUBISHI AC30TE AC30TE
Optical fiber loop system...... High speed communication of 10Mbps/25Mbps is realized.
The distance between stations, the length of the total cable length, strong anti-interference.
Coaxial bus system...... Using low cost coaxial cable, the network construction cost is lower than that of the optical fiber loop network MITSUBISHI AC30TE.
Twisted pair bus system...... Combined with high performance price ratio network module and twisted pair cable,
The construction cost of network system is very low.
I/O control in the first class of open field network module.
CC-Link based on reliable field bus technology,
Able to transmit large number of bits data (such as ON/OFF information) and word data (such as analog information) MITSUBISHI AC30TE.
Consistency of CC-Link to maintain loop transmission,
And the cycle of transmission and information (instantaneous transmission) communication separately, so as to ensure the timeliness of.
Even if the information reaches saturation, it will not affect the link scan time.For A6TBXY36/A6TBXY54/A6TBX70E (common cathode; drain type) long 5m.Input / output points: 4096 points.
Number of input and output elements: 8192.
Program capacity: 26 K step.
Processing speed: 79ns.
Program memory capacity: 144 KB.
Built in RS232 communication port.
Support installed memory card.
For A mode only.
Enhance the basic performance.
CPU''s built-in soft element memory capacity increases to up to 60K.
To increase the control, quality management data can also be processed at high speed.
Convenient processing of large capacity data.
In the past can not achieve the standard RAM and SRAM card file register area of continuous access,
The boundary of each area should be considered in programming.
The SRAM 8MB extension card is installed in the high speed universal QCPU,
Standard RAM can be used as a continuous file register,
Capacity up to 4736K words, thus simplifying the programming.
Thus, even if the memory space of the soft element is insufficient,
Can also be installed by the expansion of SRAM card, easy to extend the file register area.
The address register is extended to 32 bits, which can be programmed to go beyondd the traditional 32K word,
And to achieve the extension to the file register to all regions of the file register AC30TE.
In addition, the processing speed of the index modification plays an important role in the efficient operation of structured daata (array),
The speed has been improved AC30TE.
When the index is used to modify the program repeatedly (e.g. from FOR to NEXT), the scan time can be reduced.
