MITSUBISHI general purpose AC servo amplifier MR-J2 series.
Rated output: 0.6kw.
Interface: single axis positioning built-in type.
Voltage: single phase AC200V.
High response.
High precision positioning.
High level automatic tuning, can easily achieve gain settings.
Adopting adaptive vibration control and reducing vibration.
With a computer combination, using the software to achieve the best tuning FX2N-48ER-ES/UL
Pulse sequence input (position, speed control), analog input (speed, torque control) two purposes.
Simple operation.
The socket is arranged on the front panel, and is convenient to connect.
Using the socket, wiring easy.
Setting method and J2Super with interchangeable. Type: HA-FE series.
Rated output: 0.6KW.
Rated speed: 3000r/min.
Electromagnetic brake: there.
Control complex, easy to achieve intelligent,
The electronic commutation method is flexible and can be changed by square wave or sine wave.
Motor maintenance free, high efficiency, low operating temperature,
Electromagnetic radiation is very small, long life, can be used in a variety of environments.
AC servo motor is brushless motor, which is divided into synchronous and asynchronous motor,
Synchronous machines are commonly used in motion control,
Its power range, you can do a lot of power.
Large inertia, the maximum rotation speed is low, and with the increase of power and rapid reduction.
So it is suitable for the application of low speed and stable operation.
The rotor of the servo motor is permanent magnet,
Drive controlled U/V/W three phase electric electromagnetic field,
The rotor rotates under the action of the magnetic field,
At the same time the motor comes with the encoder feedback signal to the drive,
According to the feedback value and the target value, the driver is compared,
Adjust the rotor rotation angle.
The accuracy of the servo motor is determined by the accuracy of the encoder. Input and output points: 40 points.
Power supply: DC24V.
Input points: 24 points.
Output points: 16 points.
Output form: transistor output (source).
Power consumption: 25W.
Weight: 0.7KG.
Outline dimension: 130x90x86mm.
FX3GE on the performance of the FX3GA increased analog input / output and Ethernet communication and other built-in features.
Applicable to a wide variety of applications.
Basic unit: 24/40 point.
Third generation standard model.
High flexibility.
Suitable for small scale control of high cost PLC.
Control points to 128 points, the use of CC-Link remote I/O can control the maximum 256 points.
A versatile PLC.
Built in CPU, power supply, input and output, analog input and output, Ethernet port, can be used immediately after the purchase.
High speed operation.
Basic instructions: 0.21 s/ instruction.
Application instruction: 0.5 s/ instruction.
Large capacity memory.
Built in program memory 32000 steps.
EEPROM memory cartridge with program transfer function.
FX2N-48ER-ES/UL Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FX2N-48ER-ES/UL&select=5
