Cable length: 10.6m.
Long distance connection between CPU (A Series) and GOT for QnAS/AnSCPU/ motion controller.
Long distance connection between A7GT-CNB and GOT.
Applicable models: GT16, GT15, GT11. Servo motor series: low inertia, small capacity.
Rated output: 0.5kw.
Rated speed: 2000r/min.
Electromagnetic brake: there.
Oil seal: have.
Corresponding servo amplifier: MR-JE-10B/MR-JE-10A.
Support position control, speed control, torque control, push and press control A975GOT-TBA-CH
Position control can use linear, arc interpolation controller, fixed size feed control, target position change and other rich functions.
The position control and torque control are realized by switching control mode.
The gain adjustment of servo can be simply performed by the advanced one key tuning function.
At the same time, it is also able to suppress the low frequency vibration of the manipulator by the advanced vibration suppression control II,
Shorten the time to complete the positioning, so as to achieve the production of the rhythm of the shortening. Power supply: 120mA DC5V (PLC internal power supply), 160mA DC24V.
Analog output points: 4 points.
Voltage output: DC-10~10V.
Current output: DC0~20mA, 4~20mA.
Weight: 0.2kg.
Dimensions: 55 x 90 x 87.
The resolution of the 4 channel is 15bit binary + symbol 1bit (voltage),
High precision analog output module of 15bit binary (current).
Each channel voltage output (DC-10~10V) or current output (DC0~20mA, DC4~20mA) can be specified,
Mixed use.
With the form of the output and the upper and lower values and other rich features.
FX3UC-4AD can connect FX3GA/FX3G, FX3GE, FX3U series.
When connecting to FX3UC or FX3GC, you need FX2NC-CNV-IF or FX3UC-IPS-5V. For A6TBXY36/A6TBXY54/A6TBX70E (common cathode; drain type) long 5m.The input and output module installation number: 8.
DIN guide rail mounting adapter type: R6DIN1.
Size (H) * (32.5mm) * (W) * (D): * 328mm * 101mm. "MITSUBISHI inverter FR-A720 series.
Voltage level: 3 phase 200V.
Frequency converter capacity: 5.5KW.
Inverter output for the PWM wave, containing more harmonic.
Frequency conversion power sensor through the input voltage and current signals to exchange sampling,
Sampling value through cable, optical fiber and other transmission systems and digital input frequency conversion power analyzer,
The sampling value of the voltage and current is calculated by the digital input frequency conversion power analyzer,
It can obtain the parameters such as voltage effective value, current effective value, fundamental wave voltage, fundamental current, harmonic voltage, harmonic current, active power, fundamental wave power and harmonic power.
A975GOT-TBA-CH Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=A975GOT-TBA-CH&select=5
