Servo motor series: low inertia, medium / high power.
Rated output: 22.0kw.
Rated speed: 2000r/min.
Electromagnetic brake: No.
Shaft end specification: Standard (straight axis).
Voltage: 400V level.
Features: low inertia has low medium and high speed three models, suitable for different applications as a standard, 30KW and above servo motor can be installed flange or bracket.
IP level: IP44.
Application example:
1, injection molding machine A0J2D71
2, semiconductor manufacturing equipment.
3, large material handling system.
4, stamping machine.
Abundant motor product line can optimize the performance of the machine.
Has a rich motor product line including a rotary servo motor, linear servo motor and direct drive motor. Redundant CPU data tracking cable length of 3 meters.
Can only be used for MITSUBISHI Q series PLC redundancy CPU.Servo motor series: medium inertia, small capacity.
Rated output: 2.0kw.
Rated speed: 2000r/min.
Electromagnetic brake: No.
Power supply: 400V.
Stable driving of medium capacity and medium inertia type products.
Through the optimization of structural design, to achieve the minimum length of the industry.
High speed & high torque. Shorten the positioning time, achieve high-speed equipment.
Reducing the electric torque ripple.
Through the combination of the optimal number of the motor and the slot number, the torque ripple is greatly reduced,
To further realize the smooth constant speed device.
Improve the environmental performance of HG-SR, HG-JR series of products using IP67. MITSUBISHI motor universal AC servo amplifier MELSERVO-J3W series (a two axis servo amplifier).
Rated output A axis: 200W.
Rated output B axis: 200W.
Interface type: SSCNET type III fiber communication.
With the same high performance, multi functionality and practicality of the MR-J3-B servo amplifier,
Each MR-J3W-B servo amplifier can be used to rotate the servo motor,
Combined control of any two kinds of linear servo motor and direct drive servo motor.
The installation area can be reduced by 25% to 17% compared with two MR-J3-B servo amplifiers.
Therefore, a more compact control system can be constructed.
In addition, the two axes use the same main circuit power supply, control circuit power supply and SSCNET III communication fiber, thus greatly reducing the wiring.
A0J2D71 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=A0J2D71&select=5
